SUP Handheld Laser Welding Dual Welding Wire Delivery Mechanism

• The welding wire is an ordinary welding wire, and the common 5KG-30KG can be installed, but do not use flux-cored wire

• Adjust the strength of the roller through the Allen corner so that it is not too tight or too loose, and there is no stuttering when feeding the wire (usually it does not have to be adjusted)

• The welding wire is an ordinary welding wire, and the common 5KG-30KG can be installed, but do not use flux-cored wire
• Adjust the strength of the roller through the Allen corner so that it is not too tight or too loose, and there is no stuttering when feeding the wire (usually it does not have to be adjusted)

1.the selection of the motor: can use a single motor as a single wire feeder, the standard version of the upper motor is [A], the lower motor is [B], select A/B for double wire feeding

2.speed adjustment: parameter range [15~600cm/min].

3. Quick adjustment: long press to quickly increase/decrease mode switching.

4. Mode switching: Click to switch to [pulse mode].

5. Page switching: Click to switch to [Parameter Setting Page].

6. Status switching: Click [Stop], the wire cannot be sent; Click [Run] to feed the wire normally.

7. Manual button: long press [manual wire feeding], the motor wire out; Long press [Manual Retraction] to retract the motor.

8. Operation instructions: [Automatic wire feeding] is displayed in green, and other states are black
