Laser Cleaning Equipment
Product Description
The DMK SLCHY-500-3000 Laser Cleaning Equipment is an advanced industrial cleaning device that adopts high peak power pulsed laser, high-speed scanning system, self-developed high-precision control system and power supply from well-known domestic enterprises. It features stable and reliable performance, high efficiency and cost-effectiveness.
Compared with traditional cleaning methods, it boasts outstanding advantages: safe and non-contact operation without damaging the substrate; environmentally friendly with no secondary pollution, and the removed substances can be recycled; accurate and controllable, enabling area-specific cleaning and micron-level precision control in the thickness direction; high cost-effectiveness with no consumables required during use, only consuming electricity; strong adaptability and mobility, supporting handheld operation or integration into automation systems.
The equipment is applicable for rust removal, paint removal, oil removal and oxide film cleaning on the surface of all metals and some non-metals, as well as cleaning of black ash, carbon oil and other dirt on the surface of parts after welding. Its application fields cover aerospace, rail transportation, automotive manufacturing, marine vessels, mold processing, electronic microprocessing, food processing, stainless steel and aluminum alloy products, etc.
Product Parameters
Optical Property Parameters
|
Parameter Item |
Detailed Description |
|
Product Model |
SLCHY-500-3000 |
|
Cleaning Head Model |
Type A |
|
Laser Average Power |
500W (pulse) + 3000W (continuous) |
|
Power Adjustable Range |
10% ~ 100% |
|
Polarization Direction |
Arbitrary |
|
Laser Line Width |
5mm ~ 150mm (Adjustable) |
|
Fiber Length |
10m |
|
Minimum Fiber Bend Radius |
150mm |
|
Cooling Mode |
Water cooling (deionized water) + Industrial Air Conditioner |
|
Guided Laser Function |
Have |
|
Anti-high-reflection Function |
Have |
|
Field Lens Model |
F210/F254/F330 (Optimize according to actual working conditions) |
The above parameters are for reference only, please refer to the actual product.
Other Details
 |
 |
