DMK Air-Cooled UV Marking Subsystem

Product Overview

The SS-G-U-05C01 is a portable air-cooled UV laser marking subsystem that integrates a 355nm ultraviolet laser, high-precision galvo scanner, field lens, and intelligent control software into a single, compact unit. Designed for non-contact, high-precision processing, it delivers high-contrast marks on a wide range of materials—including plastics, resins, metals, glass, coatings, and PCB/FPC—with no material damage or thermal impact.

Thanks to the air-cooled design, no external water chiller is required. The system is plug-and-play, installation-friendly, and highly adaptable to various environments. It can also be expanded with rotary axes, vision positioning, or large-format stitching, making it ideal for curved surface marking, automated production lines, and oversized marking applications.

Key Features

Air-Cooled Design – No water chiller needed; plug-and-play for easy deployment
	High Precision, No Thermal Impact – 355nm UV laser ensures high-quality marks with minimal material interference
Compact & Portable – All-in-one design with integrated laser, scanner, and software
	Built-in Air Filtration & Humidity Detection – Simplifies maintenance and extends system life
Optional Functional Expansions – Supports rotary marking, vision alignment, and large-format processing
	Highly Integrated – Supports internal beam expander and control board integration

Product Parameters

Laser head size: 578mmX175mmX183mm Laser head weight: 12Kg
	Power box size: 578mmX175mmX183mm Power box weight: 3.5Kg

Applications

Suitable for marking plastics, metals, glass, coated surfaces, and PCB/FPC boards, the SS-G-U-05C01 is widely used in industries such as consumer electronics, semiconductors, and new energy.
